15 x 8 IMCA & WISSOTA D-HOLE WHEEL





Bassett's 15 x 8 19 lb D-Hole style beaded wheel is legal for use in IMCA, Wissota, USMTS, UMP dirt and asphalt markets. It features the same high quality CNC spun-form shell as the Inertia Advantage wheel, but at a more economical price.

  • Big tire safety bead locks tire in place at low air pressure
  • Spun-form rim shell equals higher yield strength steel and lowest runout
  • Lightest weight allowed by IMCA/WISSOTA
  • Reverse-Bell 2" backspace Right Front option available (p/n ends in RB)
  • Valve stem located behind wheel center for protection
  • Durable Black and Silver Powder Coat and Duplex Nickel Chrome Plate finishes available
Wheel Size(s) Bolt Patterns Back Spacing Weight Available Finish Price
15 x 8
5-on-5",
5-on-4.75"
5-on-4.5"
1", 2", 3", 4", 4.75"
19 lbs.
Black, Silver
Chrome
$101.10
$154.20

15 x 8 IMCA & WISSOTA D-HOLE BEADLOCK WHEEL



Bassett's 15 x 8 spun shell beadlock wheel is the only IMCA / Wissota-legal beadlock utilizing 100% spun-form shells and rings. Spun-form shells and rings are stronger, lighter and have less runout than roll-formed beadlock wheels.

  • Now features a flat Inner Ring and taller Outer Ring to protect bolt heads and perfect fit for new Bassett High Impact Mud Cover
  • Mud Cover fastener tabs are now located on Outer Ring and feature three ¼” bolt inserts
  • New thicker, high strength steel Rings offers unmatched durability and bend-resistance
  • 18 grade-8 bolts offer less stripping and faster tire changes
  • Mud Cover fastener tab bolt pattern matches Bassett Mud Cover Fastener Ring (5RFRING). Use the same Bassett High Impact Mud Cover on either the wheel or beadlock
  • Durable Black and Silver Powder Coat and Duplex Nickel Chrome Plate finishes available

Wheel Size(s) Bolt Patterns Back Spacing
Weight
Available Finish Price
15 x 8 5-on-5"
5-on-4.75"
5-on-4.5"
2", 3", 4", 4.75"
23 lbs.
Black, Silver
Chrome
$188.80
$254.00
